مشخصات، موجودی و گزینههای سفارش این قطعه را بررسی کنید.
قطعه مکمل
برند
Analog Devices
اورجینال
اورجینال
FEATURES
Input voltage range: 2.3 V to 5.5 V Maximum load current: 600 mA Low noise 0.9 μV rms total integrated noise from 100 Hz to 100 kHz 1.6 μV rms total integrated noise from 10 Hz to 100 kHz Noise spectral density: 1.5 nV/√Hz from 10 kHz to 1 MHz PSRR of 90 dB from 200 Hz to 200 kHz; 58 dB at 1 MHz, VOUT = 3.3 V, VIN = 3.8 V Dropout voltage: 120 mV typical at VOUT = 3.3 V, IOUT = 600 mA Initial accuracy: ±0.5% Accuracy over line, load, and temperature: −2.0% (minimum), +1.5% (maximum), from −40°C to +85°C Quiescent current, IGND = 4 mA at no load Low shutdown current: 0.2 μA Stable with a 10 μF ceramic output capacitor Adjustable and fixed output voltage options: 1.2 V, 1.8 V, 2.5 V, 2.8 V, 3.0 V, 3.3 V (16 standard voltages between 1.2 V and 3.3 V available) 8-lead LFCSP and 8-lead SOIC packages Precision enable Supported by ADIsimPower tool
APPLICATIONS
Regulation to noise sensitive applications: PLLs, VCOs, and
PLLs with integrated VCOs
Communications and infrastructure
Backhaul and microwave links
